Power supply
250W+

TFX-AP300W

250W+

‏‏‎

user manual

The TFX-AP300W power supply is a standard Flex-ATX unit that will fit in most small form-factor cases.  Has enough power output and connectors to run low-medium systems being used for versatile compact computing applications.

  • Apevia 300W Flex ATX Power Supply
  • Another view of the power supply
  • High stability with 5% tolerance of 5V, 3.3V & 12V output
  • High quality components and housing
  • Look at the label
  • Power cord
  • Retail box
  • 20 + 4 pin main connector can be used for 20 pin or 24 pin
  • 1 x ATX12V 4pin connector
  • 3 x SATA connector
  • 3 x 4 pin peripheral connector
  • 1 x floppy connector
Model No.
TFX-AP300W
Max. Power
300W
Material
Metal
Color
Black
Switches
Additional power rocker switch 115/230 Volt selector switch
Input
Voltage ranges:115-230V / Input freguency:60/50Hz / Input current:6A for 115V AC, 3A for 230V AC
Output
+3.3V=12A / +5V=12A / +12V=20A / -12V=0.3A / +5VSB 2.5A
Connectors
1 x 20/24pin Main Power / 1 x 12V (P4) / 3 x SATA / 3 x Peripheral / 1 x Floppy
Cooling
Forced air ventilation by 1 x 80mm fan
Dimension
80mm x 170mm x 62mm (3.23" x 6.75" x 2.5") - W x L x H
Weight
2.1 lbs
Package
10 pcs/carton
Cu'ft
1.33 (per carton)
