Power supply
250W+

ITX-AP300W

250W+

‏‏‎

user manual

Apevia ITX-AP300W power supply is a standard-size Mini-ITX / Flex-ATX unit that will fit in any ITX form-factor case.  It has enough power output and connectors to run low-medium ITX systems used for versatile compact computing applications.

  • Apevia 300W Flex ATX Power Supply
  • Another view of the power supply
  • High stability with 5% tolerance of 5V, 3.3V & 12V output
  • Look at the label
  • Power connectors
  • Retail box
Model No.
ITX-AP300W
Max. Power
300W
Material
0.5mm Metal Casing
Color
Black Matte Coating
Switches
Additional Power Switch 115/230 Volt Selector Switch
Input
Voltage ranges:115-230V / Input frequency:60/50Hz / Input current:8A for 115V AC, 4A for 230V AC
Output
+3.3V=12A / +5V=12A / +12V=20A / -12V=0.3A / +5VSB=2.5A
Connectors
1 x 20/24pin Main Power / 1 x P4 12V / 2 x Serial ATA / 2 x 4Pin Peripheral / 1 x Floppy
Cooling
Forced Air Ventilation by 1 x 40mm Double Ball Bearing Fan
Dimension
150mm x 81.5mm x 40.5mm (5.9" x 3.21" x 1.59") - L x W x H
Weight
1.8 lbs
Package
20 pcs/carton
Cu'ft
1.9 (per carton)
